Clearly, 20° is the complement of 70° and 70° is the complement of 20°.

                              Thus, the complement of angle 53° = 90° - 53° = 37°.

                  Supplementary Angles:

                  Two angles are called supplementary angles, if the sum of the two angles is two
                  right angles i.e. 180°.

                  Each angle is called the supplement of the other.

                  Example: 30° and 150° are supplementary angles, because 30° + 150° = 180°

                  6. Adjacent Angles: Two angles are said to be adjacent, if they have a common
                  vertex, a common arm and their non-common arms are on different sides of the
                  common arm.
                  ∠ABD and ∠DBC are the adjacent angles. Ray BD is their common arm and point
                  B is their common vertex. Ray BA and ray BC are non-common arms.













                                         Note: ∠ABC = ∠ABD + ∠DBC


                        Adjacent angles can be a complementary angle or supplementary
                         angle, when they share the common vertex and side.

                  Properties of Adjacent Angles

                  Some of the important properties of the adjacent angles are as follows:
                  Two angles are adjacent-angles, such that


                        They share the common vertex.
                        They share the common arm.
                        Angles do not overlap.
                        It does not have a common interior-point.
                        There should be non-common arms on both the sides of the common arm.
