Question 10:
While doing their experiment, on finding the equivalent resistance of two resistors
connected in series, three students A, B, C set up their circuits as shown here

The correct set-up is that of
(a) students A and B
(b) students B and C
(c) students C and A
(d) all the three students

Question 11:
The diagram shows a network of four resistors which are connected to an electric
source. Identify the resistors which are connected in series in this network.

(a) B, A and £>
(b) B, C and D
(c) C, D and A
(d) A, B and C

Question 12:
The given circuit diagram shows the experimental arrangement of different circuit
components for determination of equivalent resistance of two resistors connected in
series.
